1000A Anodizing Line Equipment with IEC PLC Control and Adjustable Leaching Time for Uniform Coloring

Markenbezeichnung:	MEI-ALU
Modellnummer:	EDAC-12--1000A
Mindestbestellmenge:	1 SATZ
Preis:	Verhandlungsfähig
Verpackungsdetails:	Standerverpackung exportieren
Zahlungsbedingungen:	T/T

Detailinformationen

Beschreibung des Produkts

Detailinformationen

Herkunftsort:

China

Stromversorgung Wechselstrom:

50HZ, 380V ± 10%

statische Auslaugungszeit:

0 - 180 Sekunden justierbar

Gleichstromanstiegszeit:

10 - 50 Sekunden

justierbarer Wechselstrom-Aufstieg:

25-50 Sekunden

Wechselstromverstellbar:

Dauer von 1-1800 Sekunden

Aktuell:

1000A

Versorgungsmaterial-Fähigkeit:

20 Stück/Monat

Hervorheben:

1000A Anodizing Line Equipment

IEC PLC Control Coloring Machine

Adjustable Leaching Time DC-AC Coloring Power Supply

Beschreibung des Produkts

1000A Anodizing Line Equipment with IEC PLC Control Coloring Machine

The EDAC-12 series DC-AC double wave coloring power supply is a high-energy power product developed based on advanced European technology standards (IEC-146 compliant) and specialized coloring technology. This equipment is designed for electrolytic coloring of aluminum alloy extruded profiles for architectural applications, aluminum alloy car parts surface coloring, and other specialized electrolytic coloring applications.

Advanced Coloring Technology

The DC-AC intelligent coloring power operation begins with pulsating DC output to activate the aluminum alloy surface after oxidation, followed by shaping and homogenization treatment. This process ensures consistent color deposition during subsequent AC electrodeposition of metal ions, particularly effective for light color series including champagne, stainless steel imitation, and light bronze finishes.

Key Operational Advantages

Enhanced Color Uniformity: Pulsating DC current homogenizing treatment combined with AC voltage coloring produces consistent surface coloration
Superior Process Adaptability: Excellent performance with tin salt, mixed salts, and single nickel salt formulations, including specialized single nickel salt recipes for light color reproduction
Flexible Operation: Can operate in separate AC coloring function mode when required

Main Functions & Features

Main circuit utilizes large power two induction regulator surge with contactor as circuit contact switch
PLC-controlled automatic voltage stabilization based on output voltage deviation
Digital voltage time adjustment via PLC programming
Comprehensive protection systems: current limit, pressure, and over-temperature protection
Multiple shading models for varied application requirements
Touch screen interface for state setting, parameter configuration, data display, and fault diagnostics
PLC communication capability with host computer for online control and data acquisition
Intelligent touch screen with DC+ sine wave and DC+ asymmetric wave functionality

Operating Conditions & Specifications

Indoor Use Requirements:

Maximum altitude: 1000 meters (derating applicable above 1000 meters)
Ambient temperature range: -15°C to +40°C
Relative air humidity: Less than 85%
Installation site free from insulating gas, steam, chemical deposits, dust, dirt, and explosive/etching media
No severe vibration or impact at installation location
Power supply fluctuation: Less than ±10%

Application Compatibility

Suitable for single salt, mixed salt, and nickel salt additive series products, providing exceptional performance across various aluminum alloy coloring applications with consistent, high-quality results.
